Application：
High speed horizontal and concentric taping head specially designed for fire prevention micataping
Features：
The tape tension control is done through hysteresis brake and each taping head,as well as the pullingcapstan,is independently driven by an AC servo motor.
The machine is provided with MMI+PLC control system for pre-setting taping pitch, tape tension compensation and for speed synchronization.
Specification:
| Model | Type | Plate load sizes | Spool-load size | Wire diameter | Taping speed | Tape capacity | bobbin dia(mm) |
| HD-40H | horizontal | 400X75X10(mm) | 280X75X100(mm) | 1-10(mm) | 2000(rpm) | 1000(mm) | 630-1250 |
