Application:
Cantilever arm type,without shaft,for single bobbin
Hydraulic rise bobbin and two sides top cone by motor- driven
Suit for working with extruder and twisting machine
PLC control them and synchronous with main machine
Specification:
| Pay-off rack | Take-up rack | wire bobbin outerdiameter | wire bobbin extermal width | load | wire diameter | wire-speed range | wire-speed range |
| HD-100 | TH-100 | 500-1000 | 250-750 | 1500 | 3-20 | 200 – 400 | 600 – 1000 |
| HD-125 | TH-125 | 630-1250 | 400-950 | 2500 | 4-25 | 200 – 400 | 600 – 1000 |
| HD-160 | TH-160 | 800-1600 | 600-1200 | 4000 | 5-30 | 150- 300 | 500 – 800 |
| HD-180 | TH-180 | 800-1800 | 600-1300 | 5000 | 6-35 | 100-240 | 400 – 600 |
